Polypropylene PP 2320 Natural
Code: 3326/1Related products
Product detailed description
Polypropylene PP 2320 Natural
Fillamentum Polypropylene PP 2320 is a high-tech filament made of commodity plastic polypropylene (PP). It excels by its great mechanical properties, toughness, chemical resistance, or electrical insulation.
This material repels water, therefore, it is ideal for making parts of tanks, pipelines, etc. Since it has good electrical insulation properties, it's suitable for the printing of electrical components as an alternative to PVC.
Features:
- Electrical insulator
- Thermal resistance up to 100 °C, withstands contact with hot water
- Low moisture and water absorption
- Good impact resistance
- Weather resistance
- Chemical resistance against a wide range of substances (e.g. acids, bases, salts, oils, water)
- The lowest density from our portfolio
- Flexibility down to -40 °C – standard polypropylene gets brittle below 0 °C
- Toughness, resilience in a thin layer
- Bendable without stress whitening
- Great interlayer adhesion and smooth surface
- Less flexible than competitive PP filaments
- Safe for food contact applications
- Safe for use in electrical and electronic equipment
- Recyclable, non-toxic
| Working temperature: | 225–255 °C |
| Heated bed: | 90–105 °C |
| Diameter: | 1.75 mm |
| Diameter tolerance: | +/- 0.07 mm |
| Weight: |
600 g of filament (+ 230 g spool)
|
| The length of the filament: |
260 m (1.75 mm, 600 g)
|
| RAL | Pantone | HEX: |
N/A | N/A | N/A
|
Comparison of our engineering filaments:
| Polypropylene PP 2320 | PC/ABS | Nylon FX256 | Vinyl 303 | Fluorodur | |
| Polymer base | polypropylene | blend of polycarbonate and acrylonitrile butadiene styrene | polyamide 12 | polyvinylchloride | polyvinylidene fluoride |
| Ease of 3D printing | ★★ | ★ | ★★★ | ★★★★ | ★ |
| Low ★ / high ★★★★ warping | ★★★ | ★★★ | ★★ | ★ | ★★★★ |
| Mechanical behavior | tough, resilient in a thin layer | stiff | tough, resilient in a thin layer | stiff, strong | stiff, strong |
| Flexural resistance | bendable | rigid | bendable | rigid | rigid |
| Tensile strength | ★ | ★★★ | ★★ | ★★★ | ★★★ |
| Impact strength | 184 kJ/m2 (unnotched) | 53 kJ/ m2 (notched) | 7 kJ/ m2 (notched) | ~ 5 kJ/ m2 (notched) |
5 kJ/ m2 (notched) |
| Hardness | ★ | ★★★ | ★ | ★★★ | ★★ |
| Creep resistance | ★★ | ★★★ | ★★★ | ★★★ | ★★★★ |
| Density | 0.96 g/cm3 | 1.07 g/cm3 | 1.01 g/cm3 | 1.35 g/cm3 | 1.79 g/cm3 |
|
Chemical resistance* |
acids, alkalis, alcohols, acetone, water | water, oils, and greases, alcohols, ozone, salts | wide range of chemicals, such as car fluids, alkalis, oils and greases, ozone, acetone, alcohols | alkalis, alcohols, oils and greases, water, alkalis, acids, ozone, water, even strong chemicals | car fluids, acids, oils, alcohols, toluene, benzene, chlorinated hydrocarbons, water, ozone, even strong, and harsh chemicals |
|
Chemical resistance* |
halogenated hydrocarbons, benzene, car fluids, ozone, toluene, oils | acetone, car fluids, acids, alkalis, benzene | acids, long-term contact with hot water | acetone, car fluids, certain types of acids, and alkalis | acetone, ethyl acetate, methyl ethyl ketone |
| Thermal resistance | up to 115 °C | up to 125 °C | up to 140°C | up to 70 °C | up to 150 °C |
| Low-temperature resistance | down to -40 °C |
down to -40 °C | down to -60 °C | down to -40 °C | down to -40 °C |
| Moisture sensitivity | low | medium | high | low | low |
| Weather resistance | ★★★ | ★★ | ★★ | ★ | ★★★★ |
| Combustibility | not classified | HB | HB | V-0 (self-extinguishing) | V-0 (self-extinguishing) |
| Barrier properties | ★★★★ | ★★ | ★★★ | ★★★ | ★★★★ |
| Optical properties: | white, translucent | yellowish, non-translucent | clear, transparent | brownish or black, non-translucent | white, translucent |
| Hydrolytic stability | ★★★★ | ★★ | ★★ | ★★★★ | ★★★★ |
*Always test little 3D printed object under the specific conditions of usage (chemical, temperature, time). It always depends on the conditions of processing, design, and specific type of chemicals.
The input material was carefully selected to achieve the best processability and final properties. Fillamentum’s products are always produced from the precisely specified type of material, with the highest stability across all the batches. The customers can rely on the best quality at any time they use our filament.
Additional parameters
| Category: | PP filaments |
|---|---|
| Warranty: | 2 years |
| Material: | PP |
| Color: | natural |
| Průměr struny: | 1.75 mm |
| Hmotnost návinu: | 0.6kg |
| Materiál: | PP |
| Doporučená teplota extruze (1.75 mm): | 225 - 245°C |
| Doporučená teplota podložky: | 90 - 105°C |
| Tolerance: | max. ± 0.07 mm |
| Výrobce: | Fillamentum |
| Země původu: | Česká republika |
| Délka struny: | 600 g - 260 m |
| Materiál : | polypropylene |
