CPE HG100 Neon Orange Transparent
Code: 2394/1 2394/2 Choose variantRelated products
Product detailed description
Fillamentum CPE HG100Neon Orange Transparent
CPE HG100 filament was engineered for high-technical properties, great quality, and easy printing with final properties that will dwarf all the PET-based materials. An additional monomer improves all the properties when compared with PETG filaments.
Features:
- High-technical durable long-life material
- Great impact resistance (no break)
- Good interlayer adhesion
- Easy printing as PLA
- Low fumes released
- Tensile strength, flexural strength
- High hardness
- Temperature resistance up to 80 °C
- Chemical resistance against acids, alkalis, alcohols, and hydrocarbon
- Post-processing by sanding, smoothing, painting, and gluing
- Safe to use in electrical and electronic equipment
- Safe for food contact applications (declaration sent per request)
- Safe to use in electrical and electronic equipment
- 100% Recyclable
- 30% Bio-based
- BPA-free & styrene-free
| Working temperature: | 255–275 °C |
| Heated bed: | 70–85 °C |
| Diameter: | 1.75 mm and 2.85 mm |
| Diameter tolerance: | +/- 0.05 mm |
| Weight: |
750 g of filament (+ 230 g spool)
|
| The length of the filament: |
257 m (1.75 mm, 750 g)
97 m (2.85 mm, 750 g)
|
| RAL | Pantone | HEX: |
N/A | N/A | N/A
|
Comparison of our copolyester filaments:
| CPE CF112 Carbon | CPE HG100 | PETG | PETG filaments* | |
| Impact resistance | 106 kJ/m2 (unnotched) |
no break (notched) |
85 J/m (notched) |
98–126 J/m (notched) |
| Tensile strength | 52 MPa | 48 MPa | 50 MPa | 26–45 MPa |
| Elongation at break | 8 % | 150 % | 120 % | 58–110 % |
| Hardness | 94 R-Scale | 115 R-Scale | 105 R-Scale | 108 R-Scale |
| Flexural strength | / | 71 MPa | 71 MPa | 54–74 MPa |
| Flexural modulus | / | 1860 MPa | 2150 MPa | 1600–2100 MPa |
| Wear resistance | ★★★★ | ★★ | ★ | ★ |
| Creep resistance | ★★★★ | ★★ | ★ | ★ |
| Heat resistance (HDT) |
up to 100 °C | 80 °C | 70 °C | 70 °C |
| Chemical resistance to acids, bases, hydrocarbons |
good | good | poor | poor |
*publicly accessible information from other producers
The input material was carefully selected to achieve the best processability and final properties. Fillamentum’s products are always produced from the precisely specified type of material, with the highest stability across all the batches. The customers can rely on the best quality at any time they use our filament.
Additional parameters
| Category: | CPE |
|---|---|
| Warranty: | 2 years |
| Material: | CPE |
| Color: | orange |
| Průměr struny: | 1.75 mm, 2.85 mm |
| Hmotnost návinu: | 0.75 kg |
| Materiál: | CPE HG100 |
| Odstín RAL: | N/A |
| Odstín PANTONE: | N/A |
| Doporučená teplota extruze: | 255° - 275°C |
| Doporučená teplota podložky: | 70 - 85°C |
| Tolerance: | max. ± 0.05 mm |
| Výrobce: | Fillamentum |
| Země původu: | Česká republika |
| Délka struny: | 1,75 / 750g 254 m 2,85 / 750g 97 m |
-
TDS (124.5 kB)
-
SDS (851.7 kB)
-
ROHS Česky (238.9 kB)
-
Printing guide (59.4 kB)
-
ROHS English (235.6 kB)
